High Flow Filter

Large Flow Filter is specially designed for large caliber and high throughout conditions. It adopts folding type large flow filter element, comparing with the common basket filter element and rod filter element, the folding type filter element has larger effective filtration area and more strong containment capacity, by which to reduce the equipment size and investment, and it requires less manpower for operation.

The large flow filter manufactured by PrimeFiltra Filtration are horizontal type and vertical type, and we also can provide tailor solution according to your requirements.

Available filter element can be PALL, 3M or other domestic large flow filter element.

High Flow Filter

Applications

Pharmaceutical Industry: pre-filtration of various injections, liquid medicines and injection bottle water, pre-filtration of large infusion and various antibiotics and traditional Chinese medicine injections

Food Industry: alcohol, beverages and dring waer

Electronics Industry: Pre-filtration of pure water and ultra-pure water

Petroleum & Chemical Industry: various organic solvents, acids, lye, and oil field water

Technical parameter

Design pressure :0-1.0MPa

Design temperature :0-70℃

Surface treatment: sandblasting, polishing

Material :304, 316L

Accuracy :1um~50um

Filter element size: Diameter 6 ", length 20 ", 30 ", 40"

Import and export form: flange, quick clamp
